Mobile Application Design Concept

Image of a young woman standing in front of a wall of yellow lockers

City Lockers:
Building a Mobile App from the Ground Up


Executive Summmary

Project title

City Lockers Mobile Application Design Concept

Project Type

Solo Class Project:

  • Imagined Scenario
  • Fabricated Client/Stakeholder
  • Class + Instructor Feedback provided

Opportunity

This class project began with a process of ideation, where a novel idea was developed into an application through a process of research and competitor analysis. The full UX design cycle was demonstrated through a project proposal and pitch followed by an iterative process of sitemapping and wireframing, testing, feedback and revision and, finally, with a functional interactive prototype.

Goals

  1. Develop a concept for a mobile application that serves a need or solves a problem.
  2. Demonstrate the ways in which this concept fills a gap or need for users considering audience and competition
  3. Design and test interactive prototypes (including sitemaps and wireframes)
  4. Iterate upon findings to create a satisfactory product concept

Challenge

In this imagined scenario, NeuCity is a startup based in Chicago, IL that has partnered with local governments and businesses to install rentable lockers in commuter-centric hubs of the city. NeuCity needs a simple and intuitive application that would allow users to reserve, rent and adjust rental time on the fly. The app must offer subscription options and a means of discovering locker hubs using a robust search functionality and location services. This application needs to support NeuCity’s goal of creating a simple and accessible user experience for their CityLocker initiative.

Solution

A fully realized mobile application with the following, minimum functionality:

  • Allow users to quickly and easily log in or set up an account
  • Users will be able to locate, book, and access lockers that.
    1. Are accessible 24hrs/day and 7 days a week
    2. Utilize Location services
    3. Can be reserved, changed or canceled
  • Locate locker hubs based off of search criteria (Zip code, address, etc.) if location services are disabled
  • Will feature Robust, in-app customer service
  • Edit personal settings, including push notifications, adding/editing/removing payment type(s)
  • Securely store and process payments
  • View pricing and plan options and set-up a subscription
  • Social features such as "hub location sharing"

Deliverables

  • Data reports and presentations
  • Sitemaps and Screenflows
  • Wireframes
  • High fidelity mockups
  • Development prototypes

UX Practices

  • User Interface (UI) Design
  • Client and stakeholder consideration
  • Definition phase including:
    • Project Breifing
    • Competitor and User Research
    • Scope, Timeline, Budget, & Resources
    • Functionality, tech specs, platform(s)
    • Design, branding and visual considerations
  • Sitemapping and screenflows
  • Usability Testing
  • Feedback + Iteratation
  • Wireframing & Prototyping
  • Data summerization and client reporting

Timeline

Projected timeframe: 1 year - 1 year & 6 months

Tools

  • Adobe XD
  • Lucid Chart
  • Google Applications Suite
  • iWork Applications Suit
  • Google Applications Suit

Results

A nearly fully functional prototype with over 60 screens addressing all interactions and functionality from the original project brief.

A summary of the project, test results, and the finalized information architecture, wireframes and more are viewable in the "Results" section at the end of the page or in the final report on Scribd.

Close-up of hands scrolling a tablet and 3D concept images of application screens

Process

Introduction

Setting up the project and scenario

Imagined Scenario

NeuCity, a startup based in Chicago, IL has partnered with local governments and businesses to install rentable lockers in commuter centric hubs of the city. NeuCity needs a simple and intuitive application that would allow users to reserve, rent and adjust rental time on the fly. The app must offer subscription options and a means of discovering locker hubs using a robust search functionality and location services. This application needs to support NeuCity’s goal of creating a simple and accessible user experience for their CityLocker initiative.

Functionality

The app is intended to allow users to quickly and easily set-up an account, locate, book and access lockers via their phones. Lockers are to be accessible 24 hours a day/7 days a week with robust, in-app customer service available for troubleshooting.

App Features

The application must provide functionality for users to:

  • Create an account
  • Log-in/out
  • Edit personal settings (including push notifications)
  • Add/remove payment type(s)
  • Securely store and process payments
  • Set-up a subscription (consider offering a free trial period)
  • Invite & referral programs
  • Partner org. support
  • View and select from robust privacy settings
  • View help/troubleshooting topics, contact info and submit/access support requests
  • Locate locker hubs based on in-app search criteria (Zip code, address, etc.) if location services disabled.
  • Book specific lockers for specific time slots
  • Add/edit rental period or cancel
  • Favorite/save specific locations
  • Allow user to open locker using phone (this could be a QR code or other mechanism)
  • Social features such as sharing locker/hub locations with others
  • Rating and review system

Step 1: Define

1.1 Goals

  1. Develop a concept for a mobile application that serves a need or solves a problem
  2. Demonstrate the ways in which this concept fills a gap or need for users considering audience and competition
  3. Design and test interactive prototypes
  4. Iterate upon findings to create a satisfactory product concept

1.2 Scope

  • The application must provide a service.
  • Must either be a native app (needs to be downloaded or installed on a smart phone) or can be a cross-platform browser based mobile application.
  • Must meet minimum requirements outlined under the Technical Requirments section below.

1.3 Project Breif

After initial market research, stakeholder interviews and pre-existing user data, a project brief was created and presented.

  1. Though CityLockers can be accessed by anyone, they are geared toward the common urban commuter who must carry around a substantial burden throughout their (potentially long) days in the city. Research has shown that students, cafe-going remote workers, and those who use public or non-automotive transportation are likely to benefit most from this project.

  2. Additionally, tourists looking to take advantage of local attractions will benefit from accessible onsite luggage storage.

Users will download the native application through their preferred app store (using in-store search or provided QR codes), quickly and easily set-up an account, locate, book and access these lockers all from their phone screen.

will employ either location services or search functionality to locate the most convenient locker hubs. Lockers are to be accessible 24 hours a day/7 days a week with robust customer service available for troubleshooting.

Subscription-based models in addition to one-time payment options create incentives for longterm adoption from lower prices or fees without alienating the casual user. In depth account settings and the ability to share locker hub locations with friends allow users to further customize their experience, while also increasing the user base.

Businesses are encouraged to adopt onsite lockers or request nearby hubs as increased foot traffic will undoubtedly increase sales.

Through a survey of the closest competing apps, no other service geared toward urban commuter baggage storage currently exists. Similar services specific to luggage storage include LuggageHero, Bounce, Vertoe. These companies are the top three service providers appearing on Google. These three competitors were compared and contrasted in order to find which features are best to add to the CityLockers app, and which ones to omit. These comparisons were also used to differentiate from the current competition.

Analysis

Research showed that three major competitors currently exist in the market for similar services; LuggageHero, Bounce, and Vertoe.

Top Companies Compared
Feature Luggage Hero Bounce Vertoe
Storage Type Located inside existing businesses, including retail outlets, hotels, cafes, and more. Hosted at local businesses Located within local businesses such as hotels, restaurants, and retail shops
Pricing* Per Bag: $1/hr + a one- time $2 booking fee.
Never more than $8/day (Booking fee included)
Per Bag: $5.90 per 24hr period Per Bag: $5.95/Daily

Weekly: 15% off on final total

Monthly: 30% off on final total
Insurance* $3,000 (per bag) $10,000 $5,000
Prepay/cancellation Policy No prepayment Prepayment: required

cancellation: only refunded if prior to start date/time.
Prepayment: required

cancellation: refunded
Online Reservation Online booking, no prepay Online booking Online booking
Subscription N/A N/A Plans:
5 Vertoe $20.00 /6 month cycle
$4.00/item/day 1 Vertoe = 1 item for 1 day

Unlimited: $30.00 /1 month cycle - Unlimited uses
Security Security seal Security seals "provided for max safekeeping" "Tamper-proof" security seals
Native Application No; Web Only Yes - Apple App Store + Google Play Yes - Apple App Store + Google Play

*NOTE: All features and rates calculated based on City of Chicago

Top Competitive Companies: Pros and Cons
Feature: Positive Feature: Negative
All: Online Booking Bounce: limited cancellation time period
Vertoe: Discounted subscription available All: Storage only available within businesses
All: Insurance included in booking (varying levels) All: Secure individual storage for items not offered, only seals. Items may be less secure.
Luggage Hero: Offers hourly rates Bounce/Vertoe: Require full-day/24hr long reservations (No hourly options)
Bounce/Vertoe: Native applications Luggage Hero: No Native app (only web-based)
Bounce/Vertoe: Sleek, modern and professional look/style Luggage Hero: Cartoonish look and feel
On-Demand Application Development Prediction Tables*
Application Type Total Development cost Timeline Examples
On-demand app ~$70,000 - $100,000+ (basic, per platform)* ~5-7+ months Uber, UberEATS, Postmates, Nimber, Melabiz

*Based on: "App Development Cost", MLSDev, 2021


Description Time (weeks) Unit Price Cost
User Research Round 1 7 $ $
Design Phase 8 $2,000 $16,000 7 $ $
Prototyping 2 $1,500 $3,000
Iteration Phase 8 $2,000 $16,000
App Development 12 $3,000 $36,000
App testing and maintenance 6 $1,000 $6,000
Ongoing support and maintenance N/A Approx. $12,000
Total ~$100,000

A native app posture is best suited for this product because it offers the quickest and most secure access to all the product features while maximizing control and usability.

The application will be available to download for both Android and iOS platforms in order to reach the largest audience and in conjunction with most industry trends. No single feature requires a specific operating system, so developing a cross-platform native application should not pose significant technical, time, or budgetary issues.

Additionally, a paired down, browser-based version may be offered in conjunction to increase audience and accessibility. Users who may not have the time, storage, or data-streaming ability to download a full-fledged native application can utilize this browser based version for basic features. Though the browser based version would include limited features, it still allow users to search for and book lockers (the core goal of the app). Additionally, the browser version would allow for SMS text based updates in lieu of push notifications.

The app should include, but is not limited to, these basic sections and screen count(s):

  • Sign Up / Register or Set Up
  • x2 screens minimum

    The application will need some form of sign up or setup section to begin.


  • Login and/or Start Up Screen
  • x1 screen minimum

    If already setup or signed up, the app should have a loading/sign in or start up screen.


  • Home Screen / Dashboard
  • x1 screen minimum

    After startup, the user should land on some form of home screen or account dashboard, as appropriate to your application.


  • Main Service or Functionality
  • x10 screens minimum

    This is the bulk of the screens that will allow the main service or tasks to be completed. The number and type of required screens can fluctuate greatly depending on the project, but a good rule of thumb is that if the service of the app can be completed in a few screens, it is unlikely to meet the fidelity requirements of this project.


  • User settings and/or Profile
  • x2 screens minimum

    This section will allows users control over the app settings, their profile or account information, and other account related items such as privacy, alerts or preferred means of communication.


  • Account Cancellation or Deletion Screen
  • x1 screen minimum

    There should be an easy, clear way for users to delete or cancel their account.



Step 2: Sitemaping

The sitemapping process required extensive brainstorming in order to develop a preliminary map for the information architecture of the application. From top to bottom, navigation follows a chronological process. This map served as a guide for the wireframing process, which added many more screens and navigation paths as the application evolved.

Scroll or use gestures to view full sitemap


Step 3: Wireframing

The wireframing process began by first creating all of the screens from the sitemap above in the same chronological order. After this skeleton was created, many screens were added in between to account for the myriad of features an additional navigation paths necessary for fulfilling the required functionality. Once the rough draft wireframes addressed these requirements, it was sent to three other UX designers for critique and review. Through the iterative process, critiques were used to improve wireframes until they were prototype ready.

Scroll or use gestures to view annotated Wireframes Gallery in Adobe XD​​​​​​​

Peer Feedback and Revisions

Draft wireframes were presented to peers for several cycles of feedback and iteration. This process simulated that of client feedback and revision cycles. Below are some of the most pivotal changes made

Major Wireframe changes through iteration:
  • Splash Page: Sign-up/Login options changed from separate screens to modal over Splash page
  • Home page: “Renew” button added to countdown timer
  • Locate Hubs - Map View screen: Map settings cog (bottom-right), “N” compass orientation, zoom-in/out gesture icon (top left) and change to “List View” icon added to main map portion to improve navigation, discoverability and usability.
  • Changes in button placement, orientation and wording for improved navigation, discoverability and usability.
  • Additionally navigation buttons added to Hamburger menu such as “Home” option to return to the home screen quickly and easily from any other screen.
  • Friends landing page navigation improved and news feed added.
  • Friends Search pages examples added
  • Subscription checkout process and confirmation page added

Step 4: Prototyping

Using Adobe XD, robust interactions were added to the wireframes creating a functional prototype. This rough draft prototype was then subjected to the same iterative process with two rounds of critique and review. Once all interactions evolved into a polished prototype, it was cleared for final user testing.

Tap, click, scroll or use gestures to interact with prototype in Adobe XD​​​​​​​

Results

Final Prototype

The iterative process of UX (User Experience) design is a cyclical approach aimed at continuously refining and improving a product or service based on feedback and testing. It involves several stages that are repeated multiple times throughout the design and development lifecycle.

Results from this project included a nearly fully functional prototype with over 60 screens addressing all interactions and functionality from the project brief. See the video of interactions below:

Tap or click to start video​

Future Testing & Iteration

Though several rounds of iteration occurred during the initial design process, further testing post-launch is always recommended in order to best meet user needs.
